Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth

Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth

Large Image :  Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth

Product Details:
Place of Origin: China
Brand Name: Ceyea
Model Number: 1465C/D/F/H/L-V
Payment & Shipping Terms:
Minimum Order Quantity: one
Price: $10,000/sets >=1 sets
Packaging Details: standard packaging
Delivery Time: Delivery time for minimum order quantity ≤ 30 days
Payment Terms: T/T ‌L/C
Supply Ability: 100 units/day
Contact Now Chat Now

Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth

Description
Warranty: 3 Years Type: Signal Generator
Customized Support: OEM Place Of Origin: Shandong, China
Brand Name: CAYEAR Model Number: 1465C/D/F/H/L-V
Frequency (Hz): Other Size: See Instruction Manual For Details
Waveform: Sine Amplitude Resolution: 1.0mv
Frequency Resolution: 1HZ Style: See Instruction Manual For Details
Highlight:

1465C/D/F/H/L-V sine wave generator

,

1465C/D/F/H/L-V rf signal generator

,

100kHz Frequency rf signal generator

Cayear 1465C/D/F/H/L-V Signal Generator with 100kHz-67GHz Frequency Range
Premium Signal Generation Performance

Experience superior signal generation with the Cayear 1465 series, offering exceptional frequency range and precision for demanding applications.

Technical Specifications
Model 1465C/D/F/H/L-V
Brand Cayear
Frequency Range 100kHz~67GHz
Modulation Bandwidth 1GHz
SSB Phase Noise (10GHz carrier @10kHz offset) -126 dBc/Hz
Maximum Output Power +22dBm @20GHz
Minimum Output Power -135dBm (20ns)
Product Overview
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 0
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 1
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 2
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 3
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 4
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 5
Company Information
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 6
Packaging & Shipping
Cayear 1465C/D/F/H/L-V Rf Signal Generator With 100kHz-67GHz Frequency Range 1GHz Bandwidth 7
