National Instruments 6583 FlexRIO Digital I/O Adapter Module

Customized for OEM Support and Integration

The National Instruments NI-6583 Digital I/O Adapter Module for FlexRIO (Part Numbers: 781320-02, 781320-01, 199490C-01L, 199490B-02L) is designed for high-performance digital waveform testing up to 200 MHz. Featuring 16 LVDS channels and 32 single-ended channels, this module offers versatile voltage support from 1.2V to 3.3V with 10-bit resolution.

Key Features

200 MHz maximum clock rate (300 Mbit/s data rate in double data rate mode)
35 single-ended channels (32 + 3 PFI) with 1.2-3.3V voltage range
19 LVDS/mLVS bidirectional channels (16 + 3 PFI)
Per-stick course control with 10 ns state change time
Parallel operation of single-ended and differential channels
Includes NI SHC68-H1X38 cable for easy signal breakout
Compatible with Kintex-7 and Virtex-5 FPGAs

Technical Specifications

Number of bidirectional digital channels	32
Maximum clock rate	200 MHz
Compatible FPGAs	Kintex-7, Virtex-5
Digital I/O termination	50 ohm
Maximum data rate	300 Mbits/s
Signaling type	Single-ended, differential

Product Images

Integration Details

The module includes the NI SHC68-H1X38 cable which breaks out each single-ended signal into two 0.1-inch header connectors. Single-ended links and terminal blocks must be used with the VHDCI connector, while differential links require the InfiniBand connector. Optional flying leads cables are available separately for both channel types.
