National Instruments NI-9478 C Series 16-channel Digital I/O Module with 50 μs Update Rate and 12V/24V/48V Logic Compatibility

Large Image : National Instruments NI-9478 C Series 16-channel Digital I/O Module with 50 μs Update Rate and 12V/24V/48V Logic Compatibility

Product Details:

Place of Origin:	China
Brand Name:	National Instruments
Model Number:	NI-9478

Payment & Shipping Terms:

Minimum Order Quantity:	one
Price:	$1,000/sets >=1 sets
Packaging Details:	standard packaging
Delivery Time:	Delivery time for minimum order quantity ≤ 30 days
Payment Terms:	T/T ‌L/C
Supply Ability:	100 units/day

Contact Now Chat Now

National Instruments NI-9478 C Series 16-channel Digital I/O Module with 50 μs Update Rate and 12V/24V/48V Logic Compatibility

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	NI-9478
Highlight:	16 channel Digital I/O Module , National Instruments NI-9478 , 48V logic C Series Digital Module

National Instruments 9478 C Series Digital Module

The National Instruments NI-9478 (Part Numbers: 779940-01 and 779940-02) C Series Digital Module is a 16-channel, 50 μs module compatible with all CompactDAQ and CompactRIO systems. This module features two part numbers with identical specifications, where 779940-02 includes conformal coating while 779940-01 does not.

With user-programmable current limiting for system protection, the NI 9478 is ideal for solenoid and valve control applications, capable of sinking up to 16A per module depending on channel configuration. The module supports 12V, 24V, and 48V digital I/O logic levels.

Key Features

16 digital output channels with 50 μs maximum update rate
Compatible with CompactDAQ and CompactRIO systems
12V/24V/48V digital I/O logic levels
60 VDC channel-to-ground isolation
D-Sub front-end connection type
LabVIEW FPGA compatible for custom digital protocols
Rugged design: 50 g shock and 5 g vibration resistant
Interchangeable between CompactDAQ and CompactRIO without modification

Technical Specifications

Digital Channels	16 output channels (0 input, 0 bidirectional)
Current Flow	Sinking output
Sealed Option	Available (Part Number 779940-02)
Isolation	60 VDC channel-to-ground
Supported Platforms	C Series

Industrial Applications

Designed for direct connection with industrial equipment including motors, solenoids, and relays. Optimized for interaction with various industrial logic levels and signals, ensuring high measurement accuracy for industrial deployment.
