National Instruments PXI-2598 PXI Transfer Switch Module 50Ohm Impedance 26.5GHz Bandwidth

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	PXI-2598	Frequency Range:	20hz ~ 20khz Is Divided Into 3 Frequency Bands,9kHz ~ 6GHz,250kHz~67GHz,15MHz 30MHz 400MHz 50MHz 60MHz,25MHz
Oem:	Available,YES,MOQ>100pcs,OEM	Weight:	6.4 Kg,3Kg,<28kg
Dimensions:	364(W)112(H)420(D)mm,215(W)mm109(H)mm44.5(D)mm,19417968 MM	Product Name:	High Voltage Gps Signal Generator,DDS MFG-2125 Function Generator,Arbitrary Signal Generator
Warranty:	2 Years,1 Year	Frequency Resolution:	0.00000001Hz,0.001Hz
Output Signal:	0-24mA/0-12V/,4-20mA	Power Supply:	AC 220* ( 1 10 % ) V 50* ( 1 5 % ) Hz,3.7V Battery
Ssb Phase Noise:	<-110dBc/Hz@1GHz,20KHz Carrier Offset(typical),0.001Hz	Frequency Accuracy:	±20ppm
Package:	Yes,Retail Package	Dimension:	804240mm,235mm110mm295mm
Display:	3.5-inch 480x320TFT LCD Screen,4 Inch TFT-LCD 480*320	Working Temp.:	0℃ ~+40℃
Square:	1μHz~30MHz	The Type Of Waveform:	Arbitrary Wave (including DC)
Display Size:	2.9 Inches & Under
Highlight:	PXI-2598 PXI Transfer Switch Module , 50Ohm Impedance PXI Transfer Switch Module , PXI-2598 RF Switch Module

Customized Support National Instruments PXI-2598 PXI Transfer Switch Module

The National Instruments PXI-2598 (Part Number: 778572-98) is a 50Ω, 26.5 GHz PXI transfer switch module designed for microwave or RF signal routing in ATE (Automated Test Equipment) applications. This module is ideal for basic signal routing and adding/removing components in signal paths, particularly for transferring harmonics between upconverter and downconverter modules.

Key Features

Integrated onboard relay count tracking for predictive maintenance
Designed for Measurement Category I (≤100V signal voltage)
1.25 Arms maximum carry current per channel
75 W maximum RF carry power
-35 dBm maximum switching load
50Ω nominal characteristic impedance
Electromechanical latching relays with gold-plated beryllium copper contacts
Eight SMA jacks for I/O connections

Technical Specifications

Specification	Value
Switching Bandwidth	26.5 GHz
Relay Type	Electromechanical
Maximum AC Load Current	1.25 A
Maximum AC Switching Voltage	60 V
Scan Rate	2 cycles/second
Recommended Cycling Speed	5 channels/second
Minimum Trigger Pulse Width	150 ns
Form Factor	3U, 2-slot PXI module
Weight	302 g
Bus Connector	PXI Hybrid

Relay Performance

Mechanical Relay Life: 2.5*10⁶ cycles

Insertion Loss Repeatability: <0.03 dB

Product Images

Tag:

Contact Person: ALEXLEE

Tel: +86 15626514602
