National Instruments PXI-5922 PXI Oscilloscope with 24-bit Resolution 114 dBc SFDR and 15 MS/s Sampling Rate

Large Image : National Instruments PXI-5922 PXI Oscilloscope with 24-bit Resolution 114 dBc SFDR and 15 MS/s Sampling Rate

Product Details:

Place of Origin:	China
Brand Name:	National Instruments
Model Number:	PXI-5922

Payment & Shipping Terms:

Minimum Order Quantity:	one
Price:	$10,000/sets >=1 sets
Packaging Details:	standard packaging
Delivery Time:	Delivery time for minimum order quantity ≤ 30 days
Payment Terms:	T/T ‌L/C
Supply Ability:	100 units/day

Contact Now Chat Now

National Instruments PXI-5922 PXI Oscilloscope with 24-bit Resolution 114 dBc SFDR and 15 MS/s Sampling Rate

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	PXI-5922
Highlight:	24 bit Resolution PXI Oscilloscope , 114dBc SFDR PXI-5922 , 15MS/s Sampling Rate National Instruments Oscilloscope

Customized Support for OEMs National Instruments PXI-5922 PXI Oscilloscope

The National Instruments PXI-5922 (Part Numbers: 779153-01, 779153-02, 779153-03) is a 24-bit PXI oscilloscope with flexible resolution, featuring up to 114 dBc spurious-free dynamic range and maximum sampling rate of 15 MS/s. This model provides anti-aliasing protection for each sampling rate.

Key Features

24-bit resolution with flexible resolution settings
Up to 114 dBc spurious-free dynamic range
Maximum sampling rate of 15 MS/s
Multiple voltage ranges and coupling settings
Deep onboard memory and various trigger modes
Comprehensive instrument drivers including NI-SCOPE and Scope Soft Front Panel
Programmable with LabVIEW, LabWindows/CVI, Measurement Studio, and Microsoft Visual C/C++ or .NET
Ideal for spectrum analysis, audio signals, and other precision signal measurements

Technical Specifications

Parameter	Specification
Bus Connector	PXI Hybrid
Analog Input Impedance	1 MΩ, 50 Ω
Maximum Bandwidth	6 MHz
Maximum Sampling Rate	15 MS/s
Analog Input Voltage Range	-5 V to 5 V
Analog Input Resolution	24-bit
Voltage Input Channels	2
Onboard Clock	Internal VCXO (50 kS/s to 15 MS/s)
Trigger Types	Edge, Window, Immediate, Software, Digital
Dimensions	8.5 x 0.8 x 5.1 inches
Weight	11.8 oz
Operating Temperature	0°C to 55°C

Memory Options

779153-01: 8 MB onboard memory per channel
779153-02: 32 MB onboard memory per channel
779153-03: 256 MB onboard memory per channel

Applications

When used with LabVIEW software, the PXI-5922 can function as various instruments including spectrum analyzers, DC and RMS voltmeters, frequency counters, IF digitizers, and audio analyzers. Its low distortion and low noise characteristics make it ideal for precision measurements.
