National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM

National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM
National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM

Large Image :  National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM

Product Details:
Place of Origin: China
Brand Name: National Instruments
Model Number: PXI-2522
Payment & Shipping Terms:
Minimum Order Quantity: one
Price: $1,000/sets >=1 sets
Packaging Details: standard packaging
Delivery Time: Delivery time for minimum order quantity ≤ 30 days
Payment Terms: T/T ‌L/C
Supply Ability: 100 units/day
Contact Now Chat Now

National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM

Description
Warranty: 3 Months Customized Support: OEM
Place Of Origin: American Brand Name: National Instruments
Model Number: PXI-2522
Highlight:

National Instruments PXI-2522

,

PXI-2522 PXI Relay Module

,

National Instruments PXI Relay Module

Customized Support National Instruments PXI-2522 PXI Relay Module for OEM Solutions
The National Instruments PXI-2522 PXI Relay Module (Part Number: 778572-22) leverages the inherent timing and synchronization capabilities of the PXI platform to communicate with various instruments. Users can store switch association lists in the module's memory, then utilize built-in device outputs and start motors to advance switch sequences and rapidly communicate with any PXI instrument capable of sending and receiving advanced trigger signals, including digital multimeters or oscilloscopes.
This advanced switching strategy eliminates software loading and reduces bus latency associated with traditional software-controlled switching tasks, resulting in faster testing and more repeatable cycles.
Key Features
  • 3 independent SPDT relays with 2A switching/2A carrying capacity
  • Maximum voltage rating of 100V
  • Fully programmable software with onboard relay count tracking
  • Multiple termination options with DIN160 connectors
  • Scan rate: 145 operations/second
  • Switching bandwidth: 51 MHz
  • Total relay count: 53
Software Capabilities
The NI PXI-2522 software includes an intelligent front panel that provides fully usable functionality. This intuitive interface allows users to arrange switch topologies and modify switch associations with simple clicks. Users can also utilize the debug driver session mode to troubleshoot switches during automated testing, controlling which signal paths are active, which individual relays are open/closed, and monitoring each relay's usage frequency.
Technical Specifications
Specification Value
Bus Connector PXI Hybrid
Maximum DC Switching Current 2 A
Maximum DC Switching Voltage 100 V
Relay Configuration SPDT
Switching Bandwidth 51 MHz
Number of Relays 53
National Instruments PXI-2522 PXI Relay Module With 3 SPDT Relays 2A Switching Current 100V OEM 0
System Integration
The module can be configured into complete PXI systems, with support for viewing system resources. Its versatile design makes it ideal for OEM solutions requiring reliable switching performance in automated test environments.
