National Instruments PXIe-2514 PXI Signal Insertion Switch Module with 7 Channels and 40 Ampere Current

Description
Warranty: 3 Months Customized Support: OEM
Place Of Origin: American Brand Name: National Instruments
Model Number: PXIe-2514
Highlight:

PXIe-2514 PXI Signal Insertion Switch Module

,

7 Channels PXI Signal Insertion Switch Module

,

40 Ampere Current PXI Signal Insertion Switch Module

Customized Support National Instruments PXIe-2514 PXI Signal Insertion Switch Module with Design
Product Overview

The National Instruments PXIe-2514 (Part Number: 780587-14) is an advanced signal insertion switch module featuring seven channels that allow simultaneous opening or short-circuiting of one or more fault buses. This high-performance module delivers exceptional current handling capabilities with comprehensive protection mechanisms.

Key Features
  • High current capacity: 40A continuous current per channel (25A for multiple closed paths)
  • Pulse current capability: Up to 200A for maximum 1100μs intervals
  • Power handling: 1120W maximum switching power per channel
  • Fast response: FET relays with 8μs typical operation time (35μs maximum)
  • Protection systems: Built-in safeguards against overcurrent and overtemperature conditions
  • Wide bandwidth: Greater than 800kHz for 50Ω systems
  • Reliability: Infinite typical relay lifespan when operated within specifications
Technical Specifications
Specification Value
Bus Connector PXI Express
Maximum DC Switching Current 40 A
Maximum DC Switching Voltage 28 V
Relay Type FET
Number of Channels 7
Switching Bandwidth 800 kHz
Physical Characteristics

Dimensions: 8.5 x 1.6 x 5.1 inches (216 x 41 x 130 mm)
Weight: 513 grams
Front Panel Connectors: 2x DSUB, 8-position male connectors

Applications

Ideal for verification of control equipment integrity, including full authority digital engine control (FADEC) systems and engine control units (ECUs).
