PXIe-2515 PXI Signal Insertion Switch Module 35 Channel 30V 0.25A Multimeter Assembly

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	PXIe-2515
Highlight:	PXIe-2515 PXI Signal Insertion Switch Module , 0.25A PXI Signal Insertion Switch Module , National Instruments PXIe-2515

Customizable National Instruments PXIe-2515 PXI Signal Insertion Switch Module for OEM Applications

The National Instruments PXIe-2515 PXI Signal Insertion Switch Module (Part Number: 780587-15) is a high-performance 35-channel switching module designed for routing high-speed digital I/O signals between DUT and DIO devices.

Key Features

Routes high-speed digital I/O signals between test equipment
Enables parameter testing directly on digital pins without external connections
Eliminates impedance mismatch issues during testing
Can function as PXI source measurement unit or digital multimeter
Ideal for high-speed digital device applications

Technical Specifications

Bus Connector	PXI Express
Maximum DC Switching Current	0.25 A
Maximum DC Switching Voltage	30 V
Relay Type	Reed
Number of Channels	32
Switching Bandwidth	50 MHz

Performance Characteristics

Maximum switching voltage to ground: 30V per channel
Maximum switching power: 3W per channel
Maximum switching/transmission current: 0.25A/0.3A
Typical channel-to-channel skew: <130ps across all data channels
Channel-to-control channel skew: <290ps across all data and control channels

Dynamic Features

Maximum simultaneous drive limit: 48 relays (PXI/PXI Express)
Relay rated operating time: 0.25ms
Magnetic relay design
Includes 2 BNC female and 2 VHDCI female connectors
Compatible with various optional accessories for enhanced functionality
