National Instruments SWB-2816 Reed Matrix Module Multimeter Assembly 100VDC 0.25A

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	SWB-2816
Highlight:	National Instruments SWB-2816 , SWB-2816 Reed Matrix Module , 100VDC Reed Matrix Module

Customized OEM Support National Instruments SWB-2816 Matrix Module for SwitchBlock

The National Instruments SWB-2816 (Part Numbers: 781421-16 and 781420-16) is a reed Matrix Module designed for SwitchBlock systems. Developed by National Instruments, this module simplifies wiring assembly while minimizing external inputs needed to alter internal connection routes.

Key Features

8x46 (8 rows × 46 columns) 1-wire matrix configuration
Requires only 1 slot within the SwitchBlock carrier module
Operates in three flexible modes: as a single relay card, expandable module (up to 8×276 in single carrier), or expandable in PXI chassis (up to 8×1104)
Compatible with various electronic devices including digital multimeters, oscilloscopes, power supplies, and waveform generators
Customizable multi-card assembly when combined with other SWB-2816 modules
Typical bandwidth exceeding 8 MHz

Technical Specifications

Parameter	Value
Number of Columns	46
Max DC Switching Current	0.25 A
Max DC Switching Voltage	100 V
Relay Type	Reed
Number of Rows	8
Mode (n-wire)	1-wire
Switching Power	3 W max
Carry Current	0.30 A per channel
