RMX-4120 Programmable Power Supply National Instruments 0-30V Output 75A Current

Large Image : RMX-4120 Programmable Power Supply National Instruments 0-30V Output 75A Current

Product Details:

Place of Origin:	China
Brand Name:	National Instruments
Model Number:	RMX-4120

Payment & Shipping Terms:

Minimum Order Quantity:	one
Price:	$10,000/sets >=1 sets
Packaging Details:	standard packaging
Delivery Time:	Delivery time for minimum order quantity ≤ 30 days
Payment Terms:	T/T ‌L/C
Supply Ability:	100 units/day

Contact Now Chat Now

RMX-4120 Programmable Power Supply National Instruments 0-30V Output 75A Current

Description

Warranty:	3 Months	Customized Support:	OEM
Place Of Origin:	American	Brand Name:	National Instruments
Model Number:	RMX-4120
Highlight:	RMX-4120 Programmable Power Supply , Programmable Power Supply National Instruments , National Instruments RMX-4120

Customizable Support National Instruments RMX-4120 Programmable Power Supply Device

The National Instruments RMX-4120 Programmable Power Supply (Part Number: 784761-01) is a versatile power regulation module designed for precision testing applications. This high-performance device offers comprehensive functionality within a compact 1U rack-mountable form factor.

Key Features

750W total output power capacity
Wide DC output voltage range: 0V to 30V
High current output capability: up to 75A
Single-phase input voltage: 100-240VAC, 50-60Hz
Precision regulation with ±5mV line and load regulation
Fast transient response (≤1ms)
Compliant with IEEE Std 488.2-1992 software protocol
Comprehensive display functions for monitoring

Technical Specifications

Parameter	Specification
Output Power	750W
Output Voltage Range	0-30VDC
Maximum Current	75A
Input Voltage	100-240VAC, 50-60Hz
Line Regulation	±5mV
Load Regulation	±5mV
Transient Response	≤1ms
Form Factor	1U rack height, full-width chassis

Applications

The RMX-4120 is ideal for test systems requiring precise voltage and current measurements across a wide power range. Its programmable capabilities make it suitable for automated testing environments in industrial, manufacturing, and research applications.
